TurboVentilator (Model PPSS22 )

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
24’’(610 MM) 22’’(558 MM) 15.5’’(394 MM) 24 Vanes, Stainless Steel Polypropylene Stainless Steel Twin Bearing Ensure Frictionless Rotation Even At Low Wind Velocity M.S Electro Zinc Plated Polypropylene Polypropylene 2 6201, 6202 2RS Self Lubricating Rivets sealed Aluminum alloy with washer

Turbo Ventilator (Model PPSS24)

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
27’’(686 MM) 24’’(610 MM) 15.5’’(394 MM) 28 Vanes, Stainless Steel Stainless Steel Polypropylene Twin Bearing Ensure frictionless. Rotation Even At Low Wind Velocity M.S Electro Zinc Plated Polypropylene Polypropylene 2 6201, 6202 2RS Self Lubricating & sealed Aluminum alloy with washer

Turbo Ventilator (Model SS21)

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
24’’(610 MM) 21’’(533 MM) 16’’(406 MM) 39 Vanes, Stainless Steel 0.3 thk. Stainless Steel Stainless Steel Twin Bearing Ensure frictionless. Rotation Even At Low Wind Velocity G.I High Carbon Steel Zinc Plating G.I With Electro Zinc Plating G.I With Electro Zinc Plating 2 6001 2RS Self Lubricating & sealed Aluminum alloy with washer

Turbo Ventilator (Model SS24)

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
28’’(711 MM) 24’’(610 MM) 16’’(406 MM) 39 Vanes, Stainless Steel 0.3 thk. Stainless Steel Stainless Steel Twin Bearing Ensure frictionless. Rotation Even At Low Wind Velocity G.I High Carbon Steel Zinc Plating G.I With Electro Zinc Plating G.I With Electro Zinc Plating 2 6001 2RS Self Lubricating & sealed Aluminum alloy with washer

Turbo Ventilator (Model Tiny Colored For Domestic Use)

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
24’’(610 MM) 22’’(560 MM) 15’’(391 MM) 24 Vanes, Stainless Steel Stainless Steel Stainless Steel Twin Bearing Ensure frictionless. Rotation Even At Low Wind Velocity M.S Electro Zinc Plated G.I With Electro Zinc Plating G.I With Electro Zinc Plating 2 6001 2RS Self Lubricating & sealed Aluminum alloy with washer

TurboVentilator (MODEL AL+SS 21’’)

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
24 Inches 21 Inches 16 Inches 39 Vanes, Aluminum Stainless Steel Stainless Steel Twin Bearing Ensure frictionless. Rotation Even At Low Wind Velocity G.I High Carbon Steel Zinc Plating G.I With Electro Zinc Plating G.I With Electro Zinc Plating 2 6001 2RS Self Lubricating & sealed Aluminum alloy with washer

TurboVentilator (MODEL AL+SS 24’’)

Turbine Dia Throat Dia Height Vanes/Blades Base Ring Top Plate Rotation Center Shaft Inner Arms Outer Arms No of Bearings Bearing Types Rivets
28 Inches 24 Inches 16 Inches 39 Vanes, Aluminum Stainless Steel Stainless Steel Twin Bearing Ensure Frictionless Rotation Even At Low Wind Velocity G.I High Carbon Steel Zinc Plating G.I With Electro Zinc Plating G.I With Electro Zinc Plating 2 6001 2RS Self Lubricating & sealed Aluminum alloy with washer
